| R3p | R5p | R02p | R03p | R05p | |
Specifications |
|||||
| Minimum Size Detection | 0.3 μm | 0.5 μm | 0.2 μm | 0.3 µm | 0.5 µm |
| Standard 2 channel sizes | 0.3, 0.5, μm | 0.5, 5.0 μm | 0.2, 0.3 µm | 0.3, 0.5 µm | 0.5, 5.0 µm |
| Optional 4 channel sizes | 0.3, 0.5, 1.0, 5.0 μm | 0.5, 1.0, 5.0, 10.0 μm | 0.2, 0.3, 0.5, 1.0 µm | 0.3, 0.5, 1.0, 5.0 µm | 0.5, 1.0, 5.0, 10.0 µm |
| Additional Available sizes | 0.3, 0.5, 0.7, 1.0, 3.0, 5.0 μm | 0.5, 0.7, 1.0, 3.0, 5.0, 7.0, 10.0 μm | 0.2, 0.3, 0.5, 0.7, 1.0, 2.0 µm | 0.3, 0.5, 0.7, 1.0, 3.0, 5.0 µm | 0.5, 0.7, 1.0, 3.0, 5.0, 7.0,10.0µm |
| Flow Rate | 1 CFM (28.3 LPM) | 0.1 CFM (2.83 LPM) | |||
| Dimensions | 6.65”(h) x 9.13”(w) x 4.75”(d) [16.89 x 23.19 x 12.06 cm] | 4.87”(h) x 6.50”(w) x 3.26”(d) [12.37 x 16.51 x 8.28 cm] | |||
| Weight | 6.3 lbs (2.9 kg) | 3.1 lbs (1.4 kg) | |||
| Communication | Ethernet or Serial | ||||
| Modbus Protocol | TCP or RTU or ASCII | ||||
| Data Storage Records | 3.000 | ||||
| Self Diagnostics | Laser power supply, laser current, laser power, photo detector power supply, background voltage, photo detector health. | ||||
| Web Browser | Remote access via web browser | ||||
| Validation Mode | Yes | ||||
| Alarm Light | Yes | ||||
| Enclosure | 316L Stainless Steel | ||||
| Power | 24 VDC 120W | 24 VDC 25W | |||
| Internal Vacuum Pump | 1.0 CFM with HEPA Filtered Exhaust | 0.1 CFM with HEPA Filtered Exhaust | |||
| Light Source | Laser Diode | ||||
| Calibration | Designed for ISO 21501-4 Compliance | ||||
| Zero Count Level | <1count/5 minutes per ISO 21501-4 | ||||
| Concentration Limits | 1,000,000 particles/ft3@10% (34,300,000/m3) coincidence loss suitable for ISO classes 1-8 cleanrooms | 4,000,000 particles/ft3@10% (137,200,000/m3) coincidence loss suitable for ISO classes 1-8 cleanrooms | |||
| Counting Efficiency | 50% @ minimum channel size, 100% for particles >1.5 X - 2X channel particle size | ||||
Options |
|||||
| Software | LMS Express, LMS Express RT or LMS Pharma. | ||||
| Wall Mount Bracket | Wall mountable. | ||||
| Smart Port Accessory | Temperature & Humidity probe | ||||
ApexRemote Series Particle Counting’s Latest Technology
Quick How To: ApexRemote || How to Connect with a Mobile Device
Apex represents everything that is important in a world class Environmental Monitoring System. It is the Best-In-Class sensor and meets all the industry standards. The Risk Mitigation features of Self-Diagnostics virtually eliminate data errors.
ApexR3p with pump model is available 1.0 CFM air flow rate. The self-contained vacuum pump includes HEPA filtered exhaust and will not contaminate the surrounding environment.
Apex provides real time continuous data collection at a cost effective price per point offering unmatched performance, accuracy and reliability.
Apex provides all this in an enclosure that is compatible with industry standard decontamination processes.
