| Vertex50 | |
Specifications |
|
| Size Range | 50 - 200 nm |
| Channels | 4 |
| Standard Channel Sizes | 50 nm, 100 nm, 150 nm, 200 nm |
| Flow Rate | 100 ml/min |
| Sample Volume | 5.0 mL/min |
| Zero Count Level | ≤ 20 count/L |
| Laser Source | Solid-state laser |
| Calibration | NIST Traceable |
| Communication Modes | Ethernet, Serial RS-485, 4-20mA |
| Display | TFT Color Touch Screen |
| Concentration Limit | 10,000 counts/mL @ 10% coincidence loss |
| Enclosure | 316L stainless steel |
| Sample Inlet/Outlet Connection | 1/4" Flaretek™ |
| Environmental Conditions Operating | 50°F to 104°F (10°C to 40°C), 20% to 95% non-condensing |
| Environmental Conditions Storage | 14°F to 122°F (-10°C to 50°C), up to 98% non-condensing |
| Sample Temperature | 50°F to 122°F (10°C to 50°C) |
| Sample Pressure | 20 PSI to 72 PSI (138 kPa to 496 kPa) |
| Wetted Surface Materials | Quartz, PFA, Kalrez, PTFE |
| Communication Protocol | MODBUS TCP, MODBUS Serial, 4-20mA |
| Power | External Supply: Rated input 120-240V AC 50/60Hz, 0.7A - 1.4A. Rated Output: 24V DC, 5A |
| Dimensions | 9.0”(w) x 13.4”(d) x 8.4”(h) [22.9 x 34.0 x 21.3 cm] |
| Weight | 13.5 lbs (6.1 kg) |
Accessories |
|
| Included | 24V power adapter, power cord (US/UK/EU/CN), 1.8m USB-RS485 serial cable with industrial connector, 25’ ethernet cable with industrial connector, USB flash drive with Operators Manual, 2 x 10-foot sample inlet and outlet tubes (with flared tips and lock nuts), flow cell cleaning kit, calibration certificate and carrying case. |
| Optional | Printed operating manual; additional tubing, additional serial or ethernet cables with industrial connector, flow cell cleaning kit. |
Where Gamma Immunity and Sensitivity Meet
The Vertex50 is the smallest and lightest 50nm liquid particle counter on the market. The Vertex50 has the lowest zero count levels, has integrated manual flow control and incorporates TFT Touch Screen to simplify the user interface and offer an improved local user experience. Based on state-of-the-art technology, it is backed by a two-year warranty and international support.
Gamma immunity
Lighthouse Worldwide Solutions advanced photodetector technology allowed us to improve the optical signal to noise and lower gamma-ray interference 20 times. This means if your particle counter is reporting counts there are detectable particle counts in your ultra-pure water system.
Count subtraction is not used since we have the lowest false count rate in the industry. The Vertex50 reports the counts as soon as they come in, without waiting for an arbitrary value to be reached before the counter recognizes the particle counts.
Early Detection
With early detection comes the Vertex50s proven clean-up time after an event; the Vertex50 returns to baseline counts within 120 seconds after a particle event.
Want to learn more about where Gamma Immunity and sensitivity meet? Contact your local Lighthouse representative today.
Key Features:
